Adjusting the limit switches – Hired-Hand Unitized Mega Cool: Square Bottom User Manual
Page 42
Part No. 4801-5396 Rev 5-08
Unitized System – Square Reservoir
Page 42 of 63
Adjusting the Limit Switches
Reference to Items in Detail A – Remove Limit Switch Cover
Item Description
Item
Description
1
Drive Unit
15
Hand Crank
2
Output Shaft
16
Not Used
3
Not Used
17
Not Used
4
Copper Sealing Ring
18
Mounting Bore
5 Double
Chain
19 Chain
6
Limit Switch Cover
20
Chain Coupling
7
Connector
21
Drive Pipe Shaft
8
Not Used
22
Direction Arrow
9
Terminal Box Cover
23
Not Used
10
Electric Motor
24
Worm Wheel
11 Warning
Label
25 Bracket
12
Motor Shaft
26
Not Used
13 Adaptor
27 Not
Used
14 Electric
Drill
30 Seal
Detail A
- Remove Limit
Switch Cover
