Bearing mount attachment – Hired-Hand Unitized Mega Cool: Square Bottom User Manual
Page 27
Part No. 4801-5396 Rev 5-08
Unitized System – Square Reservoir
Page 27 of 63
Bearing Mount Attachment
1.
Attach the bearing mount on the opposite end of the system from the motor.
2.
Fasten the bearing mount securely with the 1/4-20 x 1/2” bolts and 1/4-20 nuts provided.
Bearing Mount
Use nuts and bolts to attach
the bearing mount to the four
holes indicated in the guide
bracket.
