Top flashing – Hired-Hand Unitized Mega Cool: Square Bottom User Manual
Page 52
Part No. 4801-5396 Rev 5-08
Unitized System – Square Reservoir
Page 52 of 63
½”
Top Flashing
1.
Fit top flashing to top of support brackets.
2.
Bolt back flange to stringer with 1/4x11/2 hex lag screws in holes
provided in part.
3.
Attach flashing to center of top support bracket with #14x1 Tek
screw 1/2" from edge of bracket.
Top Flashing
Top flashing
Top Flashing
