Tubular motor mount attachment – Hired-Hand Unitized Mega Cool: Square Bottom User Manual
Page 30
Part No. 4801-5396 Rev 5-08
Unitized System – Square Reservoir
Page 30 of 63
Tubular Motor Mount Attachment
1.
Attach the motor mount to either the left or right track depending on which end of the system the motor is
located. Install four 1/4” bolts and nuts through the holes of the motor mount and through the respective
holes of the guide bracket.
2.
Tighten bolts and nuts securely.
Motor mount
On end where motor
will be located, attach
the motor mount to the
guide bracket.
NOTE: Attach bearing mount to
opposite end of assembly using
same procedure.
