For mounting lock motor on end of system – Hired-Hand Unitized Mega Cool: Square Bottom User Manual
Page 37
Part No. 4801-5396 Rev 5-08
Unitized System – Square Reservoir
Page 37 of 63
Lock Motor
Limit Switch
Motor
Bracket
Drive Shaft
Assembly
5. With motor mount properly aligned according to steps 1 and 2, attach to framing with 3/8x2”
Lag
screws.
For Mounting Lock Motor on End of System
1.
On the right hand end of the system, position left hand side of Mounting Bracket 9 3/4" minimum from Back Plate to
account for Cover Splice on end of system.
2.
On the left hand end of the system, position right hand side of motor 9 3/4" minimum from Back Plate to account for Cover
Splice on end of system.
Minimum
Distance to
Mounting
Bracket
9 3/4”
(24.76cm)
