Drive Pipe Connection for Lock Motor
1.
Fit end of drive pipe into sprocket (a). IMPORTANT! Make sure that end
of drive shaft is flush with end of sprocket.
2.
Weld pieces together (b).
M10xSS Bolt
Drive shaft
Sprocket
M10 Lock Nut
