Top bars, Top bar – Hired-Hand Unitized Mega Cool: Square Bottom User Manual
Page 26
Part No. 4801-5396 Rev 5-08
Unitized System – Square Reservoir
Page 26 of 63
Connect top
bar with 1/4”
Bolt and Nut
Top Bars
Attach top bars with hook
and loop strips pointed
upward.
Top Bar
1.
The Top bar attaches underneath the mounting
brackets. The Hook and loop strip faces upward.
2.
Secure the top bars to the face of the track with 1/4-20
Nuts and Bolts as shown.
