Hired-Hand Unitized Mega Cool: Square Bottom - Manual (Page 51)

Part No. 4801-5396 Rev 5-08 Unitized System – Square Reservoir Page 51 of 63
System End Covers
1.
Attach end covers to the end of each system. Insert the tab end into
the drip rail.
2.
Fasten the front flange to the inside edge of the track unit using 1/4-
20 x 1/2" Hex Bolt and 1/4-20 Hex Nut.
3. Fasten the back flange of the end cover to the post using 1/4 x 1-1/2"
Lag screws.
End Cover
End Cover End Cover
Tab End
End Cover
