CAS200 User’s Guide Chapter 4: Setup
Watlow Anafaze 63
Low Process Alarm Setpoint
This menu is used to set a low process alarm setpoint. (The
low process alarm activates when the process variable goes
below the low process alarm setpoint. It deactivates when
the process variable goes above the low process alarm
setpoint plus the deadband.)
Selectable values: Any value within the input sensor's
range
Low Process Alarm Type
This menu lets you turn off the low process alarm or set it
to the alarm function.
Selectable values: Off, Latched, Unlatched
Low Process Alarm Output Number
This menu lets you assign the digital output that activates
when the channel is in low process alarm.
Selectable values: NONE, 1 to 34
NOTE! All digital outputs are combined. Therefore you
can assign more than one alarm to the same out-
put number, and that output will be On if any of
those alarms is On.
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 LO PROC ALARM
SETPT ? 0
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 LO PROC ALARM
TYPE ? OFF
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 LO PROC ALARM
OUTPUT ? NONE
