Chapter 4: Setup CAS200 User’s Guide
46 Watlow Anafaze
Selectable values: 1, 2, or 3 inputs, or None. These
choices have the following effect:
Job Select Input Polarity
This menu lets you set the polarity of the digital inputs
used for job selection. You can set the Active state to closed
(low) or open (high).
Selectable values: High or Low.
Startup Alarm Delay
Use this menu to set a startup delay for process and
deviation alarms for all channels. The scanner does not
report these alarm conditions for the specified number of
minutes after the scanner powers up. (The scanner will
always report failed sensor alarms, no matter what startup
delay you set.)
Selectable values: 0 - 60 minutes.
Setting Enables
1 input Jobs 1-2
2 inputs Jobs 1-4
3 inputs Jobs 1-8
None (no inputs) Remote Select disabled
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
JOB SEL DIG INS
ACTIVE ? LO
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
STARTUP ALARM
DELAY ? 0 MINS
