CAS200 User’s Guide
Chapter 4: Setup
Watlow Anafaze
45
Save Setup to Job
Use this menu to save job information for every channel, to
one of eight jobs in the CAS200 battery-backed RAM.
If you have not enabled the remote job control function, you
will not be able to save a job. If you try it, you will get this
message.
Job Select Inputs
Use this menu to run up to eight jobs remotely. It lets you
set the number of job select inputs. The CAS200 uses these
inputs as a binary code that specifies the job number to run.
The number of inputs you choose in this menu controls the
number of jobs you can select remotely.
Below is the truth table that tells you which input states
select which jobs.
Digital
Input 3
Digital
Input 2
Digital
Input 1
Job #
F
F
F
1
F
F
T
2
F
T
F
3
F
T
T
4
T
F
F
5
T
F
T
6
T
T
F
7
T
T
T
8
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
SAVE SETUP
TO JOB ? 1
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
CANNOT SAVE JOB
REMOTE SELECT ON
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
JOB SELECT
DIG INPUTS ? NONE
