CAS200 User’s Guide Chapter 4: Setup
Watlow Anafaze 47
Keyboard Lock Status
This selection lets you lock the front panel operator
function key, Change SP, so that pressing this key has no
effect. If you want to use this function, turn off the
Keyboard Lock.
Selectable values: On or Off
Scanner Address
This menu allows you to set the CAS200 scanner address.
The scanner address is used for multiple scanner
communications on a single EIA/TIA-485 cable, so each
CAS200 must have a different address. Begin with address
1 for the first scanner and assign each subsequent scanner
the next higher address.
Selectable values: 1 - 32
Communications Baud Rate
This menu allows you to set the Communications Baud
Rate. If using Anascan, ensure that the program has the
same baud rate set through the ‘scaninst’ program.
Selectable values: 19200, 2400 or 9600
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
KEYBOARD LOCK
STATUS ? OFF
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
CONTROLLER
ADDRESS ? 1
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
COMMUNICATIONS
BAUD RATE ? 9600
