Chapter 2: Installation

CAS200 User’s Guide

34

Watlow Anafaze

Table 2.6

TB18 Connections

Terminal

Function

1

+5 Vdc

2

CTRL COM

3

Watchdog timer

4

Global alarm

5

Output 1

6

Output 2

7

Output 3

8

Output 4

9

Output 5

10

Output 6

11

Output 7

12

Output 8

13

Output 9

14

Output 10

15

Output 34

16

Input 1

17

Input 2

18

Input 3/Pulse input
