CAS200 User’s Guide Chapter 7: Specifications
Watlow Anafaze 99
Table 7.12 Pulse Inputs
Table 7.13 Thermocouple Range and
Resolution
* True for 10% to 100% of span except type B, which is
specified for 800°F to 3200°F.
Parameter Description
Number 1
Frequency Range 0-2000Hz
Input Voltage Protection Diodes to supply and common
Voltage Levels
<1.3 V = Low
>3.7 V = High (TTL)
Maximum Switch Resistance to
Pull Input Low
2k Ω
Minimum Switch Off Resistance 30k Ω
Thermocouple
Type
Range in °F Range in °C
Accuracy* at
25°C Ambient
Accuracy* at
0-50°C Ambient
° F ° C ° F ° C
J -350 to 1400 -212 to 760 ±2.2 ±1.2 ±3.3 ±1.8
K -450 to 2500 -268 to 1371 ±2.4 ±1.3 ±3.8 ±2.1
T -450 to 750 -268 to 399 ±2.9 ±1.6 ±5.8 ±3.2
S 0 to 3200 -18 to 1760 ±5.0 ±2.8 ±8.8 ±4.9
R 0 to 3210 -18 to 1766 ±5.0 ±2.8 ±8.8 ±4.9
B 150 to 3200 66 to 1760 ±7.2 ±4.0 ±22.1 ±12.3
E -328 to 1448 -200 to 787 ±1.8 ±1.0 ±2.9 ±1.6
N -450 to 2370 -268 to 1299 ±2.7 ±1.5 ±5.0 ±2.8
PL-II 50 to 2012 10 to 1100 ±1.9 ±1.0 ±3.1 ±1.7
