Power connections, Wiring the power supply, Power connections 19 – Watlow CAS200 User Manual
Page 31: Wiring the power supply 19, Figure 2.7— cas200 series scanner 19
CAS200 User’s Guide
Chapter 2: Installation
Watlow Anafaze
19
Power
Connections
Figure 2.7
CAS200 Series Scanner
Wiring the Power Supply
ç
CAUTION!
Use a power supply with a Class 2 rating only. UL
approval requires a Class 2 power supply.
Connect power to the scanner before any other connections.
This allows you to ensure that the scanner is working
before any time is taken installing inputs and outputs.
SCSI Port
(to TB50
)
TB2
(to power
supply)
TB1
(to signal
inputs
