Setup global parameters menu, Load a job, Setup global parameters menu 44 – Watlow CAS200 User Manual
Page 56: Load a job 44
Chapter 4: Setup
CAS200 User’s Guide
44
Watlow Anafaze
Setup Global Parameters Menu
The setup global parameters menu looks like this.
Load a Job
Selectable values: 1 to 8
The following parameters are loaded as part of a job:
•
Set points and spread values
•
Alarm functions (Off and Alarm), set points, high/low
process set points, high\low deviation set points and
deadband settings, and channel alarm delay.
ç
CAUTION!
All current job settings will be overwritten if you
select a job from memory. Save your current
programming to a job number if you want to keep
it.
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
SETUP GLOBAL
PARAMETERS?
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
LOAD SETUP
FROM JOB ? 1
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
CANNOT LOAD JOB
REMOTE SELECT ON
