Chapter 7: Specifications CAS200 User’s Guide
100 Watlow Anafaze
Table 7.14 Input Resistance for Voltage Inputs
Table 7.15 Digital Inputs
Range Input Resistance
0-12V 85k Ω
0-10V 50k Ω
0-5V 40k Ω
0-1V 7.4k Ω
0-500mV 6.2k Ω
0-100mV 1.2k Ω
Parameter Description
Number 8
Configuration
8 selectable for output override, remote job
selection
Input Voltage Protection
Diodes to supply and common. Source must
limit current to 10 mA for override conditions
Voltage Levels
<1.3V = Low
>3.7V = High (TTL)
5V maximum, 0V minimum
Maximum Switch Resistance to Pull Input Low 1k Ω
Minimum Switch Off Resistance 11k Ω
Update Rate 6k Ω
