Chapter 4: Setup
CAS200 User’s Guide
50
Watlow Anafaze
EPROM Information
This view-only display shows the scanner's EPROM
version and checksum.
Setup Channel Inputs
The Setup Channel Input main menu lets you access
menus which change parameters related to the channel
input:
•
Input type
•
Input units
•
Input scaling and calibration
The next section explains how to use the Input menus to
configure your scanner.
Input Type
This is the first menu of the Setup Channel Inputs menu.
It lets you configure the input sensor for each channel as
one of these input types:
•
Thermocouple types (J, K, T, S, R,B, PL-II, and N).
•
Linear inputs.
•
Skip (an input type available for unused channels.)
The scanning display doesn't show channels you've set
to Skip.
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
CAS200
V 1.00 CS=2233
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
SETUP CHANNEL 02
INPUT ?
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 INPUT
TYPE ? J T/C
