Chapter 4: Setup CAS200 User’s Guide
62 Watlow Anafaze
High Deviation Alarm Output Number
This menu assigns a digital output which activates when
the channel is in high deviation alarm. The digital output
only activates if you have set the high deviation alarm to
On.
Selectable values: 1 to 34, None
NOTE! All digital outputs are combined. Therefore, you
can assign more than one alarm to the same out-
put number, and that output will be On if any of
those alarms are On.
Low Deviation Alarm Type
This menu turns off the low deviation alarm or set it to the
alarm function.
Selectable values: Off, Latched, or Unlatched
Low Deviation Alarm Output Number
This menu is used to assign a digital output that activates
when the channel is in low deviation alarm.
Selectable values: 1 to 34, None
NOTE! All digital outputs are OR'd together (combined).
Therefore you can assign more than one alarm to
the same output number, and that output will be
On if any of those alarms is On.
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 HI DEV ALARM
OUTPUT ? NONE
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 LO DEV ALARM
TYPE ? LATCHED
CHANNEL PROCESS UNITS
CHANNEL NAME ALARM STATUS
01 LO DEV ALARM
OUTPUT ? NONE
