Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+56 C
Accuracy: 1.-5 ~ +10 degree around 100 degree.
2.-10 ~ +15 degree around 50 degree.
K-Type1 Temperature
: N/A
K-Type2 Temperature
: N/A
System Temperature
: +34 C
CPU FAN Speed
: 2347 RPM
VCC3C
: +3.264 V
+Vcc_core
: +1.080 V
+V5S
: +4.800 V
+V12S
: +11.968 V
+1.5V
: +1.088 V
VSB3V
: +3.280 V
VBAT
: +3.200 V
5VSB
: +5.064 V
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 9: Hardware Health Configuration
PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
System
Temperatures:
o
CPU Temperature
o
System Temperature
Fan
Speed:
o
CPU Fan Speed
Voltages:
o
VCC3V
o
+Vcc_core
o
+V5S
o
+V12S
o
+1.5V
o
VSB3V
o
VBAT
o
5VSB
