IBS-19A Series Medical Panel PC
Page 18
_LED_BLNK_TYPE for details)
Return value: If it is initialized successfully, it returns TRUE.
Remarks: Call this function to turn on/off LED IC blinking control via drivers.
D.5.8 LIGHTBAR_LED_ModeSet
Syntax: PACSM_LIGHTBAR_CTRL STD_BOOLEN LIGHTBAR_LED_ModeSet (
HANDLE hDev,
PLED_MODE_SETTINGS LED_Mode_Settings)
Parameters: hDev [IN] - Input Handle.
LED_Mode_Settings [IN] - Point to structures buffers to write. (Section D.6.4
_LED_MODE_SETTINGS for details)
Return value: If it is initialized successfully, it returns TRUE.
Remarks: Call this function to set each LED operation mode on LED IC via drivers.
D.6 Structures
D.6.1 _LED_COLOR_INFO
Syntax: typedef struct _LED_COLOR_INFO{
LED_INFO LED_Info;
int R_LEVEL;
int G_LEVEL;
int B_LEVEL;
}LED_COLOR_INFO, *PLED_COLOR_INFO;
Parameters: R_LEVEL、G_LEVEL、B_LEVEL [int] - Store the brightness level information for
R, G and B LED. The brightness level is from 0 to 7.
LED_Info [structure] – The LED IC address is stored in Main_Addr on the I2c
bus, and LED list numbers are stored in R_LN, G_LN and B_LN parameters:
typedef struct _LED_INFO {
UCHAR Main_Addr; //Main address
UCHAR R_LN; //Red list number
