IBS-19A Series Medical Panel PC
Page 34
ƒ Anti-static Discharge: If a user open the rear panel of the flat panel PC, to
configure the jumpers or plug in added peripheral devices, ground themselves
first and wear and anti-static wristband.
3.3 Installation and Configuration Steps
The following installation steps must be followed.
Step 1: Install the handset (optional)
Step 2: Connect peripheral devices to the bottom panel of the flat panel PC
Step 3: Mount the flat panel PC
3.4 Handset Installation (Optional)
An optional handset can be installed on the IBS-19A Series to make VOIP call. To install
the handset, please follow the steps below.
Step 1: Locate the two retention screw holes on the rear panel.
Step 2: Secure the handset base with the IBS-19A Series by two retention screws
(Figure 3-1).
Figure 3-1: Handset Base Installation
