IBS-19A Series Medical Panel PC
Page 26
Specification IBS-19A Series
Gamma Table Grayscale Mode - DICOM GSDF Clear Base 6500K
Grayscale Mode - DICOM GSDF Blue Base 9300K
Color Mode - Gamma 2.2 6500K
Color Mode - DICOM GSDF Clear Base 6500K
Color Mode - Gamma 2.2 9300K
Color Mode - DICOM GSDF Blue Base 9300K
Remote Control Infrared remote control for OSD control
LED Dash Light Upper: 26 x True color LED
Left: 20 x True color LED
Right: 20 x True color LED
Watchdog Timer Software programmable supports 1 sec. ~ 255 sec. system reset
RFID Optional Mifare 13.56Mhz RFID reader
Smart Card Reader Optional ISO7816-1/2/3 card reader
Wireless Connection
Wi-Fi Wireless LAN 802.11 a/b/g/n dual-band 2.4Ghz/5Ghz
Bluetooth Bluetooth 2.1 + EDR (internal USB module)
HSDPA Optional 3.5G HSDPA modem
Drive Bays
HDD Drive Bay One 2.5” 320GB/250GB SATA HDD preinstalled
ODD One Slim DVD-RW drive (24x)
Audio/Video
Webcam 1.3-megapixel CMOS Camera (1280 x 1024)
Microphone Stereo microphone
Speaker AMP 3 W + AMP 3 W (built-in stereo speakers)
Handset Optional handset with speaker and MIC
Digital TV Tuner Optional DVB-T and ISDB-T module
I/O Ports and Switches
Rear Panel I/O (Backward) 1 x External power switch connector
1 x RS-422/485 COM port connector
1 x USB 2.0 port
1 x RJ-45 for GbE LAN
Rear Panel I/O (Downward) 1 x RS-232 COM port connector
1 x HDMI port
