IBS-19A Series Medical Panel PC
Page 74
Î
Enabled D EFAULT
Legacy USB support enabled
Î
Disabled Legacy USB support disabled
Î
Auto Legacy USB support disabled if no USB devices are
connected
6.3.5 Super IO Configuration
Use the Super IO Configuration menu (BIOS Menu 7) to set or change the
configurations for the FDD controllers, parallel ports and serial ports.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Super IO Configuration
Super IO Chip
Fintek F81866
> Serial Port 1 Configuration
> Serial Port 3 Configuration
Set Parameters of Serial
Port 1 (COMA)
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 7: Super IO Configuration
