IBS-19A Series Medical Panel PC

Page 27

Specification

IBS-19A Series

2 x RJ-45 for GbE LAN

2 x USB 2.0 ports

1 x Audio mic-in connector

1 x Audio line-out connector

1 x Reset button

1 x AT/ATX power mode switch

Front Panel I/O

2 x USB 2.0 ports

Power

Power Input

9 V ~ 28 V DC

120W

Input: 90 VAC ~ 264 VAC @ 50 Hz / 60 Hz

Power Adapter

(Medical Grade)

Output: 12 V DC

Physical

Mounting

Wall, Stand, Arm (VESA 100 mm x 100 mm)

Construction Material

Anti-bacteria plastic front frame

Dimensions (mm) (W x H x D)

466 x 428 x 65

Net Weight

7.1kg

Environment

Operation Temperature

0ºC ~ 40ºC

Storage Temperature

-20ºC ~ 60ºC

IP Level (Front Panel)

IP 65

EMC/Safety

UL60601-1, EN60601-1, CE (60601-1-2), FCC class B

Table 1-4: System Specifications
