3.7.1 Arm Mounting

The IBS-19A Series is VESA (Video Electronics Standards Association) compliant and

can be mounted on an arm with a 100 mm interface pad. To mount the IBS-19A Series on

an arm, please follow the steps below.

Step 1:

The arm is a separately purchased item. Please correctly mount the arm onto

the surface it uses as a base. To do this, refer to the installation documentation

that came with the mounting arm.

NOTE:

When purchasing the arm please ensure that it is VESA compliant and

that the arm has a 100 mm interface pad. If the mounting arm is not

VESA compliant it cannot be used to support the IBS-19A Series.

Step 2:

Once the mounting arm has been firmly attached to its surface, lift the IBS-19A

Series onto the interface pad of the mounting arm.

Step 3:

Align the retention screw holes on the mounting arm interface with those in the

IBS-19A Series. The IBS-19A Series arm mount retention screw holes are
