IBS-19A Series Medical Panel PC
Page 65
6.1 Introduction
A licensed copy of the BIOS is preprogrammed into the ROM BIOS. The BIOS setup
program allows users to modify the basic system configuration. This chapter describes
how to access the BIOS setup program and the configuration options that may be
changed.
6.1.1 Starting Setup
The UEFI BIOS is activated when the computer is turned on. The setup program can be
activated in one of two ways.
1. Press the D ELETE
or F2 key as soon as the system is turned on or
2. Press the D ELETE
or F2 key when the “Press Del to enter SETUP” message
appears on the screen. 0.
If the message disappears before the D
ELETE
or F2 key is pressed, restart the computer
and try again.
6.1.2 Using Setup
Use the arrow keys to highlight items, press E
NTER
to select, use the PageUp and
PageDown keys to change entries, press F1 for help and press E
SC
to quit. Navigation
keys are shown in the following table.
Key Function
Up arrow Move to the item above
Down arrow Move to the item below
Left arrow Move to the page on the left hand side
Right arrow Move to the page on the right hand side
+ Increase the numeric value or make changes
- Decrease the numeric value or make changes
Esc key Main Menu – Quit and do not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu --
Exit current page and return to Main Menu
