IBS-19A Series Medical Panel PC
Page 76
Î
IO=3F8h;
IRQ=3, 4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4
Î
IO=2F8h;
IRQ=3, 4
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3, 4
Î
IO=3E8h;
IRQ=3, 4
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ3, 4
Î
IO=2E8h;
IRQ=3, 4
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ3, 4
6.3.5.1.2 Serial Port 3 Configuration
ƒ Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled Disable the serial port
Î
Enabled D EFAULT
Enable the serial port
ƒ Device Settings [IO=3E8h; IRQ=11]
The Device Settings option is set to “IO=3E8h; IRQ=11” by default and can not be
changed.
ƒ Device Mode [RS422/485]
The Device Mode option is set to “RS422/485” by default and can not be changed.
6.3.6 H/W Monitor
The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds and
system voltages.
