IBS-19A Series Medical Panel PC
Page 18
1.3 Features
The IBS-19A Series features the following:
ƒ Intel® Core™ i5/i3 or Pentium® processor
ƒ Intel® H61 chipset
ƒ 2.0 GB DDR3 SO-DIMM preinstalled
ƒ 802.11 a/b/g/n wireless module
ƒ LED dash light design
ƒ Five USB 2.0 ports (three on the rear, two on the front)
ƒ Watchdog timer that triggers a system reset if the system hangs for some
reason
ƒ IP 65 compliant front panel
ƒ AT or ATX power mode
ƒ 5-wire resistive type touch screen
ƒ Anti-bacteria housing
ƒ RoHS compliance
1.4 External Overview
1.4.1 General Description
The stylish IBS-19A Series panel PC is comprised of a screen, rear panel and bottom
panel. An ABS/PC plastic front frame surrounds the front screen. The rear panel provides
screw holes for a wall-mounting bracket compliant with VESA FDMI standard. The I/O
interfaces facing backward and downward on the rear panel provides access to external
interface connectors that include LAN, USB 2.0, serial ports, reset button, HDMI, audio
connectors, power connector, power switch connector and AT/ATX mode switch.
1.4.2 Front Panel
The front side of the IBS-19A Series is a flat panel TFT LCD screen surrounded by an
anti-bacteria plastic frame. The webcam and microphone are located at the top center of
the front panel. Two USB 2.0 ports and the optional smart card reader are also located on
the front panel (Figure 1-2).
The front panel also includes two sensors and two control buttons:
