IBS-19A Series Medical Panel PC

Page 62

5.3 Turn off the Power

WARNING:

Failing to turn off the system before opening it can cause permanent

damage to the system and serious or fatal injury to the user.

Before any maintenance procedures are carried out on the system, make sure the system

is turned off.

5.4 HDD Replacement

The IBS-19A Series is preinstalled with one HDD. To replace the HDD, follow the

instructions below.

Step 1:

Follow all anti-static procedures. See Section 5.2.

Step 2:

Turn off the power. See Section 5.3.

Step 3:

Remove the HDD cover by removing the HDD cover retention screw (Figure

Figure 5-1: HDD Cover Retention Screw
