IBS-19A Series Medical Panel PC
Page 46
Figure 3-17: AT/ATX Switch Location
Step 2: Adjust the switch according to the preferred setting.
3.6.1 AT Power Mode
With the AT mode selected, the power is controlled by a central power unit rather than a
power switch. The IBS-19A Series panel PC turns on automatically when the power is
connected.
3.6.2 ATX Power Mode
With the ATX mode selected, the IBS-19A Series panel PC goes in a standby mode when
it is turned off. The panel PC can be easily turned on via network or a power switch in
standby mode.
3.7 Mounting the System
WARNING!
When mounting the flat panel PC onto an arm, onto the wall or onto a
panel, it is better to have more than one person to help with the installation
to make sure the panel PC does not fall down and get damaged.
The four methods of mounting the IBS-19A Series are listed below.
ƒ Arm mounting
ƒ Stand mounting
ƒ Wall mounting
The four mounting methods are described below.
