IBS-19A Series Medical Panel PC
Page 25
1.5 Internal Overview
The IBS-19A Series has the following components installed internally:
ƒ Motherboard
ƒ 2.0 GB 1333 MHz DDR3 SO-DIMM
ƒ Wireless module
ƒ Bluetooth module
ƒ 320GB/250GB SATA HDD
ƒ Slim DVD-RW drive
1.6 System Specifications
The technical specifications for the IBS-19A Series systems are listed in Table 1-4.
Specification IBS-19A Series
CPU Intel® Pentium® G620T 2.2G CPU
Intel® Core™ i3-2100T 2.5G CPU
Intel® Core™ i5-2390T 2.7G CPU
Chipset Intel® H61
Memory Pentium® G620T:
One 204-pin 2 GB 1333 MHz DDR3 SO-DIMM preinstalled
Core™ i3/i5:
Two 204-pin 1 GB 1333 MHz DDR3 SO-DIMM preinstalled
(system max. 8GB, dual SO-DIMM slot)
LCD Size 19”
Max. Resolution 1280 x 1024
Contrast Ratio 2000:1
Brightness (cd/m 2 ) 300
Viewing Angle 89/89/89/89
Backlight LED
Backlight MTBF 50,000
Touch Panel 5-wire resistive type
OSD Keys Six OSD keys (LCD on/off, audio up/down, brightness up/down)
One programmable function key
