Drop Ceiling
Finished Floor
Installed Valance Kit
Hood Valance Kit (Optional)
The valance kit size is determined by AVI Hood size and distance from the finished floor
to the installed drop ceiling height. The valance kit screws directly to the AVI Hood and does not
require any structural support. All kits have provisions for hood fire suppression piping to pass
through without modification. The plastic coating must be removed from all parts prior to installa-
tion.
AVI hood valance kits are available for different floor to ceiling heights. Contact XLT
Ovens or your designated representative for more information.
