Hood Weight (Does not include ovens)

AVI

1832

AVI

2440

AVI

3240

AVI

3255

AVI

3270

AVI

3855

AVI

3870

Single Stack

560.39

[254]

644.84

[292]

708.73

[321]

757.05

[343]

790.12

[358]

812.03

[368]

845.32

[383]

Double Stack

513.78

[233]

576.72

[262]

640.25

[290]

681.29

[309]

704.08

[319]

728.01

[330]

750.23

[340]

Triple Stack

594.64

[270]

593.48

[269]

657.82

[298]

698.99

[317]

709.52

[322]

840.39

[381]

754.55

[342]

NOTE: All weights in pounds [kg].

NOTE: All dimensions in inches [mm] unless otherwise noted.

69 1/2

±1/8

[1765

±3.2

]

(90 [2286])

Front of Hood Canopy

Switches to be on
Front of the Hood

Finished Floor

Hood Dimensions
