Base Assembly
Insulation
Installed Oven Decks
Oven Assembly
1. Fully insert the lifting jacks into the lifting pipe.
2. Raise the oven high enough to clear the cart or the skid.
Failure to engage properly can result in damage, injury, or death from a falling
oven.
WARNING
Both jacks should be raised in unison, otherwise they may bind and a dangerous
situation may develop.
Do not put any part of yourself under the oven at any time.
The oven is top heavy. Be careful!
WARNING
3. Remove the cart or skid.
4. Rotate the oven as shown.
5. Roll the appropriate oven base underneath the oven.
6. Lower the oven onto the base.
7. Repeat as necessary
Stacking the Ovens
