Version 2.0 SAS InFusion User Manual
40
LeCroy Corporation
Test Actions
After you enter the set of events for a test state, the menu-driven interface prompts you
for the corresponding action or set of actions. If you define multiple actions, the actions
occur simultaneously. Table 9 lists supported actions. Note that some of these actions
only apply to creating sequences.
Table 9 Test State Actions
1 Only shown in Action Properties dialog box when creating a sequence.
2 In SAS InFusion, a Remove primitive action is implemented by replacing the primitive
with an idle data dword. A Remove frame action is implemented by replacing the
start-of-frame and end-of-frame primitives with an idle data dword.
Action Description
Beep Emit audible sound of duration selectable via drop-down list.
BNC Output Send a signal out the BNC port to the box downstream.
Branch to
Existing State 1 Go to a state in this sequence that is already defined. 1
New State 1 Go to a state in this sequence that is not yet defined (you need to define it). 1
Capture Data Dword Captures a data dword into one of four registers.
Disconnect Put both SAS InFusion SAS ports at electrical idle immediately.
Inject CRC Error Inject a CRC error into the line.
Invalid 10b-code
Error Inject invalid 10b code into the line.
Running Disparity
Error Inject a Running Disparity (RD) error into traffic.
Monitor/Count Open a window to count the number of events that occur during a session. A
session is the time period during which a scenario runs.
Reconnect Start traffic pass-through immediately. This action is used to restart traffic
after a previous disconnect command. Once traffic is passing-through, the
initiator and target resume OOB signaling.
Remove 2 Remove the targeted event from the traffic. 2
Restart All Sequences 1 Restart all sequences in the scenario. 1
Current Sequence 1 Restart the sequence that contains this action definition. 1
Stop Scenario Stop all scenario activity.
Substitute Data Dword Substitute a data Dword in the traffic.
SAS Primitive Substitute a SAS primitive in the traffic.
SATA Primitive Substitute a SATA primitive in the traffic.
