Version 2.0 SAS InFusion User Manual
38
LeCroy Corporation
Table 8 Test State Events
Event Description
Address Frame Occurrence of a specified address frame.
Any Dword Occurrence of any dword.
ATA Command Occurence of a particular ATA command.
ATA Command Frame Occurrence of a particular ATA command frame.
[+] ATAPI Occurence of a particular ATAPI command from the list that includes MMC4,
RBC, SBC2, SMC2, SMC2, SPC2, SPC3 or SSC2.
BNC Input Occurrence of BNC input trigger.
Both Links Up Occurrence of both line ports active (not idling).
CRC Error Occurrence of a CRC error.
Dword Matcher Occurrence of a particular dword.
FIS Frame Occurrence of a particular FIS frame.
FIS Type Occurrence of a particular SATA FIS type.
Frame Type Occurrence of a particular frame type.
Invalid 10b-code Error Occurrence of an invalid 10b code.
Links Speed 3G Both lines operating at 3 Gbps.
Links Speed 6G [Not supported in this version.]
OOB Signal Occurrence of OOB signal.
Primitive Group Occurrence of particular primitive group.
Running Disparity Error Occurrence of Running Disparity (RD) error.
SAS Data Pattern Occurrence of a particular data pattern in a SAS frame.
SAS Primitive Occurrence of a particular SAS primitive.
SATA Data Pattern Occurrence of a particular data pattern in a SATA frame.
SATA Primitive Occurrence of a particular SATA primitive.
{+} SCSI Occurence of a particular SCSI command from the list that includes MMC4, RBC,
SBC2, SMC2, SMC2, SPC2, SPC3 or SSC2.
SMP Frame Occurrence of a particular SMP frame.
SSP Frame Occurrence of a particular SSP frame.
Timer Occurrence of a particular elapsed time (time period).
