SAS InFusion User Manual Version 2.0
LeCroy Corporation
87
Submenus
The Root menu has four options:
•
Box Setup submenu (Table 18).
•
SAS Configuration submenu (Table 19).
•
Start Infusion command.
•
Infusion Setup submenu (Table 20).
Within each of these submenus are second-level submenus.
Note: When lists of options are presented in a menu, current selections are
indicated with an asterisk
To navigate through submenus, use the Up Arrow and Down Arrow buttons (top and
bottom blue buttons) on the front of the unit. To select or change an option, use the
Select button (middle button).
Box Setup
Submenu
Table 18 Box Setup Submenu
Menu Submenu Command
IP Mode Static
Dynamic Static = you assign an IP address
Dynamic = A DHCP server assigns an IP address
IP Address Default is 0.0.0.0. If IP Mode = Dynamic, this field is ignored.
Subnet Mask Default is 0.0.0.0 If IP Mode = Dynamic, this field is ignored.
Default Gateway Default is 0.0.0.0 If IP Mode = Dynamic, this field is ignored.
Reboot Cancel
Confirm Selecting Confirm causes SAS InFusion to save the current
configuration and reboot.
Shutdown Cancel
Confirm Selecting Confirm causes SAS InFusion to save the current
configuration and shutdown.
About Displays status on the following parameters:
Subnet Mask:
Default Gateway:
BootCode:
Firmware:
Bus Engine:
IP Mode: (Dynamic or Static)
Loop Mode: (Infusion) - This option is disabled.
NOTE: To go back to the previous menu, press the Select
button (i.e., the middle button)
[ Back ] Returns to Root menu.
