Gilderfluke&Co 'Smart' Brick Animation Control System User Manual

Page 89

asked for the range of shows that you want to play.
Each time this edge is triggered, then the next show
in this range will be played. As an example of this, if
you select a range of shows of ten to twenty: Show
ten will be played on the first on the first edge, show
eleven on the next, etc.. After show twenty plays,
then the next show will be show ten again. Each
time this window is displayed, the ‘next’ show which
will be played on each input which has been set
for sequential operation will be displayed.

If the range of shows is just one show, then the

text displayed will show that only a single show will
be requested and played on this input.

b) Randomly: If you select this option, then you are

asked for the range of shows that you want to play
on this input. Each time this edge is triggered, one
of the shows within this range will be chosen at ran-
dom and played. As an example of this, if you se-
lect a range of shows of ten to twenty: Show ?? will
be played on the first on the first edge, show ?? on
the next, etc.. The randomizer uses a separate
counter for each of these inputs. This counts at ten
Hertz from the first show selected through the last
and then recycles. When the user selects an input
which has been configured with this option, the
Smart Brick Brain uses the current value of this coun-
ter to select and play a next show. If the randomizer
played the same show the last time, it will spin the
randomizer another time to try and select another
show to play. If after this second spin, the same
show comes up, then it will be played.

c) Normally: The inputs will behave as described

above. You can select whether the input will pause,
