Gilderfluke&Co 'Smart' Brick Animation Control System - Manual (Page 154)

Sw #1 Sw #2 Sw #3 Memory Size @15 FPS @16 FPS @30 FPS @32 FPS
OFF OFF OFF 8192 9:06 8:32 4:33 4:16
ON OFF OFF 16,384 18:12 17:04 9:06 8:32
OFF ON OFF 32,768 36:24 34:08 18:12 17:04
ON ON OFF 65,536 1:12:49 1:08:16 36:24 34:08
OFF OFF ON 131,072 2:25:38 2:16:32 1:12:49 1:08:16
ON OFF ON 262,144 4:51:16 4:33:04 2:25:38 2:16:32
OFF ON ON 524,288 9:42:32 9:06:08 4:51:16 4:33:04
ON ON ON 1,048,576 19:25:05 18:12:16 9:42:32 9:06:08
Switch #4: Double Show:
When this switch is turned on, the MiniBrain will divide
the installed memory on the Smart Bricks into two sepa-
rate ‘shows’. Which show is being played is selected
using the ‘Blue’ input. When this input is active, the sec-
ond bank is selected. When this option is selected, you
can not also clock the MiniBrain externally. Both these
functions use the Blue input. The capacities of each
show will be as follows when switch #4 is ON:
Sw #1 Sw #2 Sw #3 Each Show @15 FPS @16 FPS @30 FPS @32 FPS
OFF OFF OFF 4096 4:33 4:16 2:16 2:08
ON OFF OFF 8192 9:06 8:32 4:33 4:16
OFF ON OFF 16,384 18:12 17:04 9:06 8:32
ON ON OFF 32,768 36:24 34:08 18:12 17:04
OFF OFF ON 65,536 1:12:49 1:08:16 36:24 34:08
ON OFF ON 131,072 2:25:38 2:16:32 1:12:49 1:08:16
OFF ON ON 262,144 4:51:16 4:33:04 2:25:38 2:16:32
ON ON ON 524,288 9:42:32 9:06:08 4:51:16 4:33:04
Switch #5: Frame Rate:
Switch #6: Frame Rate:
These two switches are used to select the frame rate
being used by the MiniBrain. They are used as follows:
