255 possible shows, just hit the ape key when it
pauses between pages. You can store these counts for
later printing or archive by telling your computer to save
any incoming text to a file, and then invoking this com-
mand. After all of the screens have printed, tell your
computer to stop saving text. This file that your computer
creates can be later pasted into any word processor or
other program. This is exactly how we make the illustra-
tions in these manuals.
Input Triggering Commands:
“1” 'GREEN' Input Closing Edge:
“2” 'GREEN' Input Opening Edge:
“3” 'BLUE' Input Closing Edge:
“4” 'BLUE' Input Opening Edge:
“5” 'PB' Input Closing Edge:
“6” 'PB' Input Opening Edge:
“7” '1/4 J6 Port' Input Closing Edge:
“8” '1/4 J6 Port' Input Opening Edge:
“9” Countdown End:
Each Rack Smart Brick Brain has two opto-isolated ex-
ternal inputs, one push button input on the front, and
one 1/4 J6 Port input (8 optoisolated inputs). Additionally,
the Smart Brick Brain treats the end of a countdown just
like it would treat any of the other inputs. These com-
mands are used to select what actions will take place
on each edge of each of these inputs. Note that both
rising and falling edge actions are available to you. This
allows you to to do things like start a show on a closing
edge and then stop it on the opening edge of the
same input. This would make it into a ‘run while’ input.
The closing edge on the 'GREEN', 'BLUE, and 'PB' in-
puts are considered to be when a normally open push
button or switch is closed. The opening edge is when
