BYTE 14 = SPACE
BYTE 15 & 16 = DISPLAY HOURS
BYTE 17 = COLON
BYTE 18 & 19 = DISPLAY MINUTES
BYTE 20 = COLON
BYTE 21 & 22 = DISPLAY SECONDS
BYTE 23 = PERIOD
BYTE 24 & 25 = DISPLAY FRAMES
BYTE 26 = SPACE
BYTE 27 & 28 = DIPSWITCH 1
BYTE 29 = SPACE
BYTE 30 & 31 = J-6 PORT
BYTE 32 = CARRIAGE RETURN
BYTE 33 = LINE FEED

EXAMPLE: to poll the status for Smart Brick Brain 00:

i 0 0

82 10 02 039D 02:00:05.08 30 00

This would tell you that the Smart Brick Brain is running

an internally clocked show, that the system is currently
cycling shows, that the thumbwheel switch is set to ‘1’,
the show number is ‘02’, the frame being addressed in
the Smart Bricks is 039D, the time into the show is 5.08
seconds, that record is enabled and we are using 64K
Smart Bricks, and that there is no input to the J-6 port.

“k” (track#) Smart Brick Brain Status:

This command responds with the following informa-

tion for the Smart Brick Brain specified by the TRACK#:

BIT 0 = STORED START RECEIVED
BIT 1 = CYCLING SHOWS FLAG
BIT 2 = DOING DELAY BETWEEN SHOWS
BIT 3 = DOING SHOW END
BIT 4 = LaserDisk (or DVD) CLOCKED SHOW
BIT 5 = EXTERNALLY CLOCKED SHOW
BIT 6 = Smpte CLOCKED SHOW
BIT 7 = INTERNALLY CLOCKED SHOW

EXAMPLE: to poll the status of the Smart Brick Brain ad-

dressed at 00:
