Gilderfluke&Co 'Smart' Brick Animation Control System - Manual (Page 21)

- 6264LP RAM -
To configure a Record/Playback Smart Brick for use with
6264LP static RAM Chips for a capacity of 16,384 (16K) frames.
As shown, the RAM chips must be ‘South’ justified, leaving four un-
used holes at the top of each socket.
0
channel
U8
1
channel
U7
2
channel
U6
3
channel
U5
U14 (ch 0)
U13 (ch 1) U12 (ch 2)
U11 (ch 3)
JP3
JP2 DMX-
512
in/out
DMX-512 Address DMX heart Brain heart DMX data DMX Error
U17 26LS32
JP6
DMX-512
Forever!
Yes No
6264LP 6264LP 6264LP 6264LP
