ASCII Characters to be Received:

If you need to get a response from the serial port, you simply

enter the character with bit seven set. These characters will be
displayed on the menu with parentheses around them and bit
seven hidden to show that they are response characters rather
than ones which will be sent. The first character is a special char-
acter unique to the Smart Brick System. Response ASCII charac-
ters translate into HEX as follows:

ASCII

HEX

ASCII

HEX

ASCII

HEX

ASCII

HEX

don’t care

80h

DLE

90h

SPACE

A0h

0

B0h

SOH

81h

DC1

91h

!

A1h

1

B1h

STX

82h

DC2

92h

A2h

2

B2h

ETX

83h

DC3

93h

#

A3h

3

B3h

EOT

84h

DC4

94h

$

A4h

4

B4h

ENG

85h

NAK

95h

%

A5h

5

B5h

ACK

86h

SYN

96h

&

A6h

6

B6h

BELL

87h

ETB

97h

A7h

7

B7h

BS

88h

CAN

98h

(

A8h

8

B8h

HT

89h

EM

99h

)

A9h

9

B9h

LF

8Ah

SUB

9Ah

*

AAh

:

BAh

VT

8Bh

ESC

9Bhh

+

ABh

;

BBh

FF

8Ch

FS

9Ch

,

ACh

<

BCh

CR

8Dh

GS

9Dh

-

ADh

=

BDh

SO

8Eh

RS

9Eh

.

AEh

>

BEh

SI

8Fh

VS

9Fh

/

AFh

?

BFh

ASCII

HEX

ASCII

HEX

ASCII

HEX

ASCII

HEX

@

C0h

P

D0h

`

E0h

p

F0h

A

C1h

Q

D1h

a

E1h

q

F1h

B

C2h

R

D2h

b

E2h

r

F2h

C

C3h

S

D3h

c

E3h

s

F3h

D

C4h

T

D4h

d

E4h

t

F4h

E

C5h

U

D5h

e

E5h

u

F5h

F

C6h

V

D6h

f

E6h

v

F6h

G

C7h

W

D7h

g

E7h

w

F7h

H

C8h

X

D8h

h

E8h

x

F8h

I

C9h

Y

D9h

i

E9h

y

F9h

J

CAh

Z

DAh

j

EAh

z

FAh

K

CBh

[

DBh

k

EBh

{

FBh

L

CCh

\

DCh

l

ECh

|

FCh

M

CDh

]

DDh

m

EDh

}

FDh
