- Smart Brick Brain 1/4 J6 Setup Menu -

This menu is used to configure the individual optically isolated

inputs on the 1/4 J6 cable. The last two settings on the menu can
also be set on the main menu. Because this menu shows a
snapshot of the state of the 1/4 J6 input each time it redraws, it is
also a useful tool for diagnosing wiring problems with this port.

- Gilderfluke & Co. Rack Smart Brick Brain - rev. 2.00 copyright 1991-2000 DCM -

1/4-J6 Input Setup

PAUSE CONT. STOP

INPUT and EDGE [rtz] [inc] START LOOP STOP at END TAPE DECK

a) J6 input Closing: |______|______|______|__on__|______|______|_________|

b) J6 input Opening: |______|______|______|______|______|______|_________|

0) bit 0 (now = closed): sequentially start shows __5 thru _17 (next = __5)

1) bit 1 (now = open ): randomly start (loop) shows _22 thru _42

2) bit 2 (now = open ): randomly start (loop) shows _55 thru 117

3) bit 3 (now = open ): loop show #__8: '***_Show___8_***'

4) bit 4 (now = closed): Direct select show __5: '***_Show___5_***'

5) bit 5 (now = open ): Direct select show __6: '***_Show___6_***'

6) bit 6 (now = open ): Select schedule 12

7) bit 7 (now = open ): Select schedule 17

c) select from J6- yes

d) direct select- yes

m) more... o) load defaults r) download configuration x) eXit

enter command-

Input Triggering Commands:

“a” '1/4 J6 Port' Input Closing Edge:

“b” '1/4 J6 Port' Input Opening Edge:

Each Rack Smart Brick Brain has two opto-isolated ex-

ternal inputs, one push button input on the front, and
one 1/4 J6 Port input. Additionally, the Smart Brick Brain
treats the end of a countdown just like it would treat any
of the other inputs. These commands are used to select
what actions will take place on each edge of each of
the 1/4 J6 Port inputs. Note that both rising and falling
