the appropriate times.
“j” Coin-Op Mode:
This toggle turns on a special mode that is typically
used with animation systems that are installed in coin
operated devices. When this toggle is switched ON:
1) If no other show is playing and we aren’t in a delay
countdown, the Rack Smart Brick Brain will start
playing show 255/FFh. This can be stopped if there
is a closure on the BLUE input.
2) The end of the delay countdown will always call up
show 255/FFh.
Show 255/FFh is then programmed as the ‘attract’ mode
for the installation. Other shows are typically called up
randomly or sequentially by the coin acceptor switch.
“k” Select from J6:
If more than one show is stored on a single Smart
Brick System, each one can be accessed individually
and played back. Up to two hundred fifty-five of these
shows can be stored on a single Smart Brick System.
These requests can be made through the serial port or
through the 1/4 J6 Port.
This toggle enables the 1/4 J6 Port for requesting the
shows on this Smart Brick System. There are two methods
of selecting shows from this port. Which one is used is se-
lected by the DIRECT SELECT command.
“l” Direct Select:
This command is used to switch the 1/4 J6 Port over to
selecting one of eight shows directly, instead of using bi-
nary inputs for requesting up to two hundred fifty-five dif-
ferent shows. The DIRECT SELECT is useful when you have
eight or less shows which need to be called up through
