- Disabling the Outputs When Stopped -

This jumper plug must be installed for the Smart Brick to work. It

has two possible positions. This position will cause all of the out-
puts to turn off whenever the Smart Brick System stops advancing
frames and the ‘running delay’ counter has run out. This is useful
if damage might result from leaving certain outputs in your sys-
tem turned on indefinitely, as could occur if the system were
stopped while those outputs were active.

0

channel

U8

1

channel

U7

2

channel

U6

3

channel

U5

U14 (ch 0)

U13 (ch 1)

U12 (ch 2)

U11 (ch 3)

JP3

JP2

DMX-

512

in/out

DMX-512 Address

DMX heart Brain heart

DMX data

DMX Error

U17

26LS32

JP6

DMX-512

Forever!

Yes

No
