Page 124

the system. If the ‘DELAY’ flag is set, then the Smart
Brick Brain will check to see if the thumbwheel switch
on its front is set to anything other than 0. If it is, then
it will then start this new delay countdown. At the
end of the countdown, whatever ‘Countdown end’
actions are set will take place just as though a
switch closure input had just happened. In most
cases this will be another LOOP command, which
will then start the next show. At the end of that show,
the whole process will then start over.
Stop:
This command will stop any show which is play-
ing immediately and unconditionally.
Stop at End:
This command resets the ‘LOOPING SHOWS’
flag. This means that the shows will stop playing at
the normal end of show and won’t start a new
countdown under any circumstances, and won’t
chain unless the ALLOW CHAINS flag is set and
there is a request for an IMMEDIATE CHAIN at the
end of the current show.
Tape Deck:
These allow you to trigger the START, STOP or
REWIND relay outputs from one of the external in-
puts or end of countdown.
1/4 J6 Input Triggering Commands:
“0” Bit 0 Input Closing Edge:
“1” Bit 1 Input Closing Edge:
“2” Bit 2 Input Closing Edge:
“3” Bit 3 Input Closing Edge:
“4” Bit 4 Input Closing Edge:
