enFORCE DSP1500 SAN Unit Operation Manual
(Rev 4) PAGE 6－22
Chapter 6: System Operation
¾ Data number 37 Distance High Limit Stop / Distance Sampling / Deadman Function
□ □ □ □
0: Distance High Limit Stop [Yes] (Default)
1: Distance High Limit Stop [No]
* When set to “1”, Stroke Distance Limit [00-33] is used for judgment.
0: 0.1mm distance sampling (Default)
1: 0.01mm distance sampling
2: 0.005mm distance sampling
* For correct waveform sampling, the speed should be at or less than
20mm/sec. for 0.1mm, 2mm/sec. for 0.01mm and 1mm/sec. for 0.005mm.
Deadman Function:
0: Normal (Default)
1: Home Position Search Only
2: Return Only
3: Home Position Search and Return
RS232 Output Select:
0: No Data Output (Default)
1: Press Result Data Output
2: Waveform Display
¾ Data number 38 Band Check *
□ □ □ □
0: Disable [No] (Default)
1: Enable [Yes]
*(Requires Main Unit firmware version 1.06 and/or SAN Unit firmware version 3.11
minimum)
¾ Data number 39 (Reserved for special functions. Do Not Use.)
* Data number 40, 41, 42 and 43 require the use of a SAN3-DP(1 or 2)S module (new
version) and SAN Unit firmware version 3.18 minimum.
¾ Data number 40 Real Time Clock - Date: Year Data
□ □ □ □
¾ Data number 41 Real Time Clock - Date: Month / Day Data
□ □ □ □
¾ Data number 42 Real Time Clock - Time: Hours / Minutes Data (24 Hour Clock)
□ □ □ □
¾ Data number 43 Real Time Clock - Time: Seconds Data
□ □ □ □
8 0 0 2 = “2008”
9 0 7 = “07 / 09” (July 9 th )
0 1 5 1 = “15:10” (3:10PM)
0 5 = “:50”
