enFORCE DSP1500 SAN Unit Operation Manual
(Rev 4) PAGE 6－24
Chapter 6: System Operation
Item
Parameter No.
PARM
Data No.
D-NO
DATA
Speed
０１～３２ ７０ Slow Start Speed [mm/sec]
０１～３２ ７１ Approach Speed [mm/sec]
０１～３２ ７２ Part Search Speed [mm/sec]
０１～３２ ７３ Press Speed 1 [mm/sec]
０１～３２ ７４ Press Speed 2 [mm/sec]
０１～３２ ７５ Decompression Speed [mm/sec]
０１～３２ ７６ Return Speed [mm/sec]
¾ Data Number 00 Press Mode（Press Method＋Judgment Operation＋Loading
Direction＋Return Operation）
This data field will set the Press Method, Judgment Operation, Loading Direction and
Return Operation.
□ □ □ □
Press Method
0: Load Control
1: Distance Control
2: Specified Point Load Judgment
3: Load Rise Detection
4: Specified Range Peak Load Judgment
5: Time Controlled Press
6: Load Drop Detection
7: Load Drop Detection (Point Stop)
8: Distance Control with Load Limit
Judgment Operation
0: Final Load Low Limit Judgment Disable
1: Final Load Low Limit Judgment Enable
2: Final Load Low Limit Judgment Disable + Part 3 Check
3: Final Load Low Limit Judgment Enable + Part 3 Check
* 4: Final Load Low Limit Judgment Disable + Band Check
* 5: Final Load Low Limit Judgment Enable + Band Check
(*Must be enabled in System Setting [00-38] to use)
Loading Direction
0: Positive Load (Default)
1: Negative Load
Return Operation
0: Return
1: [ACCEPT] Return, [REJECT] No Return
2: [ACCEPT] No Return, [REJECT] Return
3: [ACCEPT] and [REJECT] No Return
4: Jog Return
5: Keep Load
6: Load Ignore Return
7: Load Return (Software version 1.94 or later)
*For further detailed Press Mode instruction, see the following items.
